4×T8‑32W Electronic Fluorescent Ballast, 120‑277V, UL & cUL Listed Class P Type HL, DOE Energy Conservation Compliant

  • 120‑277v t8‑32 ballast 4 lamp

  • FEILON ELECTRONICS

Availability:
Quantity:
Inquire Add to Basket

This 4‑lamp T8‑32 electronic ballast is designed for commercial fluorescent lighting systems, supporting wide input voltage 120‑277V. Fully UL & cUL listed (Class P, Type 1 Outdoor, Type HL), it complies with ANSI C82.11‑2002, ANSI C62.41‑2002, FCC Part 18 and DOE energy conservation standards, ideal for new installation and old‑ballast replacement projects.

Item

Specification

Model

4×T8‑32 Electronic Ballast

Input Voltage

120‑277V,60Hz

Lamp Quantity

4 Lamp for T8‑32W

Certification

UL/cUL Listed Class P, Type HL

Compliance

ANSI, FCC Part18, DOE Energy Standard

Sound Rating

A

Max Ambient Temp

55℃(131℉)

Tc Temperature

90℃(194℉)

Remote Mount

Max 18ft,18AWG

Dimension

9.5"×1.3"×1.1"

Weight

1.10 lbs
