127S-3.5mm 3.81mm 45 Degree Wiring Screw PCB Terminal Block Copper Environmentally Friendly Solder Plate 127S Connector

Home » Products » Terminal Blocks » PCB Screw Terminal Block » 127S-3.5mm 3.81mm 45 Degree Wiring Screw PCB Terminal Block Copper Environmentally Friendly Solder Plate 127S Connector

127S-3.5mm 3.81mm 45 Degree Wiring Screw PCB Terminal Block Copper Environmentally Friendly Solder Plate 127S Connector

Rated voltage/Current :300V/10A
Wire Capacity :26-16AWG
Pitch :3.5 ,3.81mm
Poles :02P-24P
Housing Material: PA66 UL94V-0
Contact Material :Copper Alloy
Stripping Length :5mm
Screw/Torque: M2/0.2N.M
Operation Temp.: -40-105degree
Noted: The color and packing accept customer made

Model:
127S-3.5-XXP 127S-3.81-XXP
Brand:
FEILON
Code:
127S-3.5-XXP 127S-3.81-XXP

Availability:

Quantity:



Inquire Add to Basket

Product Description

127S-3.5/3.81	Rated voltage/Current	300V/10A
	Wire Capacity	26-16AWG
	Pitch	3.5 ,3.81mm
	Poles	02P-24P
	Housing Material	PA66 UL94V-0
	Contact Material	Copper Alloy
	Stripping Length	5mm
	Screw/Torque	M2/0.2N.M
	Operation Temp.	-40-105degree
	Noted	The color and packing accept customer made
