Specification
The average rated life is 8000 hours
ceramic lamp set, antioxidant,radiation protection
Different diameter of lamp by customer's request.
are made of high purity quartz glass.
OEM & ODM acceptable
Application
Disinfection, air condition and some home appliance, used in hospital, hotel, restaurant, house, office’s air disinfection and in the surface sterilization of material.
Specification
Single-end 4pin UV Germicidal Lamp | |||||||
Lamp Type | Tube | Length | Lamp | Lamp | Lamp | 254nm UV output | Average |
mm | mm | W | mA | V | μm/cm² | Hours | |
ZW10D15W-Z212 | 15 | 212 | 10W | 425 | 22-39 | 21-24 | 8000 |
ZW14D15W-Z287 | 15 | 287 | 14W | 425 | 28-39 | 31-35 | 8000 |
ZW15D15W-Z303 | 15 | 303 | 15W | 425 | 30-40 | 33-37 | 8000 |
ZW17D15W-Z356 | 15 | 356 | 17W | 425 | 34-46 | 48-54 | 8000 |
ZW23D15W-Z436 | 15 | 436 | 23W | 425 | 40-55 | 62-69 | 8000 |
ZW28D15W-Z550 | 15 | 550 | 28W | 425 | 51-69 | 85 | 8000 |
ZW37D15W-Z793 | 15 | 793 | 37W | 425 | 78-101 | 110 | 8000 |
ZW40D15W-Z842 | 15 | 843 | 40W | 425 | 81-99 | 120-130 | 8000 |
ZW55D15W-Z1149 | 15 | 1149 | 55W | 425 | 122-149 | 150-180 | 8000 |
ZW75D15W-Z1554 | 15 | 1554 | 75W | 425 | 173-210 | 180-210 | 8000 |
ZW80D19W-Z846 | 19 | 846 | 80W | 800 | 120 | 240-270 | 8000 |
ZW120D19W-Z1149 | 19 | 1149 | 120W | 800 | 170 | 330-380 | 8000 |
ZW150D19W-Z1554 | 19 | 1554 | 150W | 800 | 220 | 400-450 | 8000 |
ZW240D19W-Z1554 | 19 | 1554 | 240W | 1800 | 190 | 650-680 | 8000 |
ZW320D19W-Z1554 | 19 | 1554 | 320W | 2200 | 180 | 800-830 | 8000 |
Remark: No-ozone, ozone and high ozone uv lamp
Can be customized the power and length based on customer requirements
