Specification
The average rated life is 8000 hours
ceramic lamp set, antioxidant,radiation protection
Different diameter of lamp by customer's request.
are made of high purity quartz glass.
OEM & ODM acceptable
| H-type UV Germicidal Lamp | |||||||
| Lamp Type | Tube Diameter | Length | Lamp Power | Lamp Current | Lamp Voltage | 254nm UV output @1M | Average Life |
| mm | mm | W | mA | V | μW/cm² | Hours | |
| PLS 5W | 12mm | 107/85 | 5W | 180 | 30-40 | 14 | 8000 |
| PLS 7W | 12mm | 137/115 | 7W | 175 | 42-62 | 16 | 8000 |
| PLS 9W | 12mm | 167/145 | 9W | 170 | 54-66 | 23 | 8000 |
| PLS 11W | 12mm | 237/215 | 11W | 155 | 81-99 | 38 | 8000 |
| PLS 13W | 12mm | 186/164 | 13W | 300 | 48-62 | 40 | 8000 |
| PLL 18W | 17mm | 217/195 | 18W | 375 | 52-64 | 57 | 8000 |
| PLL 24W | 17mm | 317/295 | 24W | 345 | 77-97 | 94 | 8000 |
| PLL 36W | 17mm | 411/379 | 36W | 435 | 98-118 | 147 | 8000 |
| PLL 40W | 17mm | 533/501 | 40W | 385 | 130-150 | 155 | 8000 |
| PLL 55W | 17mm | 533*501 | 55W | 550 | 110-130 | 170 | 8000 |
| Application | |||||||
| Hospital operating room, ward disinfection, sterilization, deodorization and purification equipment etc; | |||||||
| Medical disinfection machine, photocatalytic air purifier and aquarium disinfection etc. | |||||||
| Remark: No-ozone, ozone and high ozone uv lamp; G23,GX23,2G7,2G11,G32q Lampholder; Can be customized the power and length based on customer requirements; | |||||||
