15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block
Home » Products » Terminal Blocks » Pluggable Terminal Block » 15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block
15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block
15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block 15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block
15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block 15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block
15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block 15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block
15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block 15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block
15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block 15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block
15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block 15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block

loading

15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81 Plug type male and female green terminal block

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
telegram sharing button
sharethis sharing button
Rated voltage/Current :300V/8A
Wire Capacity: 28-16AWG/0.2-1.5mm2
Pitch: 3.5mm/3.81mm
Poles: 2P~24P
Housing Material  : PA66/UL94V-0
Contact Material :Copper alloy
Stripping Length :5-6MM
Screw/Torque :M2/0.2 N.M
Operation Temp.: -40-105degree
Noted :The color and packing accept customer made


  • 15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81

  • FEILON

  • 15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGVC-3.81 15EDGRC-3.5 15EDGRC-3.81

Availability:
Quantity:
Inquire Add to Basket

15EDGK-3.5

15EDGK-3.81

 Rated voltage/Current 300V/8A
Wire Capacity 28-16AWG/0.2-1.5mm2
Pitch 3.5mm/3.81mm
Poles 2P~24P
Housing Material PA66/UL94V-0
Contact Material Copper alloy
Stripping Length 5-6MM
Screw/Torque M2/0.2 N.M
Operation Temp. -40-105degree
Noted The color and packing accept customer made

15EDGVC-3.5,3.81 Rated voltage/Current 300V/8A
Pitch 3.5,3.81mm
Poles 2P-24P
Housing Material PA66/UL94V-0
Contact Material Copper alloy
Operation Temp. -40-105degree
Noted The color and packing accept customer made

15EDGRC-3.5,3.81 Rated voltage/Current 300V/8A
Pitch 3.5,3.81mm
Poles 2P-24P
Housing Material PA66/UL94V-0
Contact Material Copper alloy
Operation Temp. -40-105degree
Noted

The color and packing accept customer made
29-06 29-13 34


Previous:
Next:
15EDGK-3.81 15EDGK-3.5 15EDGRC-3.81 15EDGRC-3.5 15EDGVC-3.81 15EDGVC-3.5 plug terminal block male terminal block female terminal block male and female terminal block
